Internal Burnishing Tools

Next > >

Send Inquiry

Product Code : DT/DB

Brand Name : DYNEMECH SYSTEMS

Product Description

We are putting our best efforts in manufacturing, exporting and supplying a premium quality array of Internal Burnishing Tools. Positioned at helix angle in order to facilitate self feed, these tools are manufactured at our premises with the use of defect free raw materials. Best suited to be used for polishing of various components, these tools are checked by quality experts on different aspects to ensure their flawlessness. Moreover, interested clients can purchase the provided Internal Burnishing Tools in plethora of specifications at reasonable prices from us.

Features:

Smooth finish
Excellent functionality
Easy to install
Long life

Roller Burnishing Tools:

DT - Thru Bore Series
DB - Blind Bore Series
DT & DB series are designed to burnish long thru & blind bores upto 60 mm respectively.
In DT series rollers are positioned at a helix angle to provide self feed.

Model	Bore dia mm	ADJ. Range mm	Shank Size	REA50CH (mm)
Model	Bore dia mm	ADJ. Range mm	Shank Size	R50	R1	R2	R3
DT/DB 500-1000	05-10	-0.1/+0.2	MT1	50	90	150	NA
DT/DB 1001-1300	11-13	-0.1/+0.3	MT1	50	90	150	NA
DT/DB 1400-2400	14-24	-0.2/+0.4	MT2	50	90	150	300
DT/DB 2500-4000	25-40	-0.2/+0.6	MT2	100	150	300	400
DT/DB 4100-6000	41-60	-0.2/+0.6	MT2/MT3	100	150	300	400
