Anti Vibration DLK Mounts

Anti Vibration DLK Mounts
Anti Vibration DLK Mounts
Product Code : Rubber-Metal Mounts
Brand Name : Dynemech Systems
Product Description
Anti Vibration DLK Mounts

Screw Support Mounts - Series DLK

Dynemech Screw Support Mounts Series DLK are simple and effective vibration dampers for machines with respective holes in the base. These mounts offer both low frequency attenuation and stable machine leveling.

The DLK Series of Vibration damping and leveling mounts provide fast and easy installation of machines. These Anti-vibration mounts provide enhanced component finish/part tolerance and extend tool and machinery life. The machine mounts provide improved health protection and better structural safety. DLK series Anti-vibration mounts have steel body and are used for machines having mounting holes in the base. This leveling mount has a cover plate and dimpled bottom plate holding the insulation plate. Leveling is done by tightening the bolt which lifts the cover plate with the machine foot. The vibration insulating Base pad is made of composite material at varying composition giving different natural frequencies to provide vibration damping solutions to all types of industrial machines. These vibration isolation plates are resistant to water, almost all the coolants, chemicals, fuels, lubricating oils used in the modern machine shop. These vibration insulating machine pads will not deform plastically, if the weight of machine does not exceed maximum load value of the insulation plates.

Technical Specifications

Model

Load (Kg/pc)

Bolt Size

Dia(mm)

H (mm)

Adjust. Range (mm)

Applications

DLK1-a

580

M12 x 100

92

48

8

Applications: Textile Machines, CNC Machines, Power Presses, Plastic injection Moulding Machines, Pressure Die Casting Machines, Printing and Textile Machines etc. Textile Machines, Compressors, Grinding Machines,
All types of Heavy Industrial Applications.

DLK1-b

750

M12 x 100

92

48

8

DLK1-c

900

M12 x 100

92

48

8

DLK2-a

1200

M16 x 100

135

50

8

DLK2-b

1900

M16 x 100

135

50

8

DLK2-c

2600

M16 x 100

135

50

8

DLK3-a

2900

M20 x 150

187

50

10

DLK3-b

3400

M20 x 150

187

50

10

DLK3-c

4200

M20 x 150

187

50

10
