Welcome to Dynemech Systems Pvt. Ltd

Screw Support Mounts, Series DLK-4

2830 INR/Number

Get a Price/Quote

Product Details:

Size Size: Dia - 238mm & Ht - 80mm
Usage Applications: Textile Machines,CNC Machines,Power Presses,Plastic injection Moulding Machines,Pr
Product Type VIBRATION CONTROL
Weight Load Capicity 4000 to 6000 (kg,/pc) Kilograms (kg)
Color Yellow & Red
Function REDUCING VIBRATION
Application Applications: Textile Machines, CNC Machines, Power Presses, Plastic injection Moulding Machines, Pressure Die Casting Machines, Printing and Textile Machines etc. Textile Machines, Compressors, Grinding Machines, All types of Heavy Industrial Applications.
Supply Ability : 100 Number Per Day
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Price And Quantity

Price 2830 INR/Number
Minimum Order Quantity 10 Number

Product Specifications

Product Type VIBRATION CONTROL
Usage Applications: Textile Machines,CNC Machines,Power Presses,Plastic injection Moulding Machines,Pr
Size Size: Dia - 238mm & Ht - 80mm
Color Yellow & Red
Function REDUCING VIBRATION
Application Applications: Textile Machines, CNC Machines, Power Presses, Plastic injection Moulding Machines, Pressure Die Casting Machines, Printing and Textile Machines etc. Textile Machines, Compressors, Grinding Machines, All types of Heavy Industrial Applications.
Feature REDUCING VIBRATION
Weight Load Capicity 4000 to 6000 (kg,/pc) Kilograms (kg)

Trade Information

FOB Port RAI
Payment Terms Cash Against Delivery (CAD), Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque
Supply Ability 100 Number Per Day
Delivery Time 6-7 Days
Sample Policy Contact us for information regarding our sample policy
Packaging Details Wooden Box & Corrugated Box as per your requirement.
Main Export Market(s) Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa
Main Domestic Market All India, South India, Central India, North India, East India, West India, Andaman and Nicobar Islands, Andhra Pradesh, Assam, Arunachal Pradesh, Bihar, Chhattisgarh, Chandigarh, Delhi, Dadra and Nagar Haveli, Daman and Diu, Gujarat, Goa, Haryana, Himachal Pradesh, Jammu and Kashmir, Jharkhand, Karnataka, Kerala, Lakshadweep, Madhya Pradesh, Maharashtra, Mizoram, Meghalaya, Manipur, Nagaland, Odisha, Punjab, Pondicherry, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, Uttar Pradesh, Uttarakhand, West Bengal
Certifications ISO 9001:2015

Product Description

Screw Support Mounts - Series DLK

Dynemech Screw Support Mounts Series DLK are simple and effective vibration dampers for machines with respective holes in the base. These mounts offer both low frequency attenuation and stable machine levelling.

The DLK Series of Vibration damping and leveling mounts provide fast and easy installation of machines. These Anti-vibration mounts provide enhanced component finish/part tolerance and extend tool and machinery life. The machine mounts provide improved health protection and better structural safety. DLK series Anti-vibration mounts have steel body and are used for machines having mounting holes in the base. This leveling mount has a cover plate and dimpled bottom plate holding the insulation plate. Leveling is done by tightening the bolt which lifts the cover plate with the machine foot. The vibration insulating Base pad is made of composite material at varying composition giving different natural frequencies to provide vibration damping solutions to all types of industrial machines. These vibration isolation plates are resistant to water, almost all the coolants, chemicals, fuels, lubricating oils used in the modern machine shop. These vibration insulating machine pads will not deform plastically, if the weight of machine does not exceed maximum load value of the insulation plates.

Model	Load (Kg/pc)	Bolt Size	Dia(D) mm	H mm	Adjust. Range mm	Applications
DLK1-a	580	M12 x 100	92	48	10	Applications: Textile Machines, CNC Machines, Power Presses, Plastic injection Moulding Machines, Pressure Die Casting Machines, Printing and Textile Machines etc. Textile Machines, Compressors, Grinding Machines, All types of Heavy Industrial Applications.
DLK1-b	750	M12 x 100	92	48	10
DLK1-c	900	M12 x 100	92	48	10
DLK2-a	1200	M16 x 100	135	50	10
DLK2-b	1900	M16 x 100	135	50	10
DLK2-c	2600	M16 x 100	135	50	10
DLK3-a	2900	M20 x 150	187	50	12
DLK3-b	3400	M20 x 150	187	50	12
DLK3-c	4200	M20 x 150	187	50	12
DLK4-a	4000	M24 x 150	229	78	20
DLK4-b	5000	M24 x 150	229	78	20
DLK4-c	6000	M24 x 150	229	78	20
NOTE: DLK1 - Bolt Sizes - M10, M12, M16, M20 can also be supplied on request. DLK2 - Bolt Sizes - M10, M12, M16, M20, M24 possible on special request. DLK3 - Bolt Sizes - M10, M12, M16, M20,M24 possible on special request. DLK4 - Bolt Sizes - M10, M12, M16, M20, M24, M30 possible on special request.

Advantages of Dynemech DLK Mounts:

1. Different products/customized solutions possible.

2. Simple integration into the production plant due to flexible installation.

3. Significantly increased productivity without higher breakdown risk

4. Extended Tool And Machinery Life.

5. Better Structural Safety.

6. High precision levelling and accurate alignment possible.

ad value of the insulation plates.

Enter Buying Requirement Details

+ Add Attachment

Email Id

Mobile number

Please Wait...

Other Products in 'Screw Support Mounts' category

Screw Support Mount, Series DLMS (RA) Minimum Order Quantity : 5 Price : 1 INR/Number Weight : Load Capacity : 70 to 15680 kg/pc Kilograms (kg) Size : Size:Dia :59 mm To 276 mm & Height: 104 mm To 109 mm Application : DLMS Series find applications where corrosion resistant materials for hygienic, climatic and environmental reasons are required like in pharmaceutical, food and beverages processing and packaging units, Medical Equipment Manufacturing , Chemical processing industries, Assembly Equipment and Semiconductor Processing Equipments Color : GREY Usage : ALL INDUSTRIAL SETUPS Product Type : VIBRATION CONTROL Function : REDUCING VIBRATION Material : Rubber, Iron, Steel Height : Height: 104 mm To 109 mm Millimeter (mm)

Send Inquiry

Screw Support Mounts, Series DLM Minimum Order Quantity : 10 Price : 500 INR/Number Weight : LoaLoad Capacity : 150 to 4900 kg/pc Kilograms (kg) Size : Size: Dia 59mm To 276mm & Ht 14mm To 54mm Application : Applications: Compressors, Tool Room Machines, Plastic injection Moulding Machines, Pressure Die Casting Machines, Shaper, Printing and Textile Machines etc. Color : Green Usage : ALL INDUSTRIAL SETUPS Product Type : VIBRATION CONTROL Function : REDUCING VIBRATION Material : Rubber, Iron, synthetic rubbers Feature : REDUCING VIBRATION

Send Inquiry

Screw Support Mounts - Series DLT Minimum Order Quantity : 5 Price : 1470 INR/Number Weight : 0.05 Kg to 18 Kg approx. Kilograms (kg) Size : Size: Dia 80mm TO 2400mm & Ht 31mm To 68mm Application : Applications: Compressors, Tool Room Machines, Plastic injection Moulding Machines, Pressure Die Casting Machines, Shaper, Printing and Textile Machines etc. DLT2u 350 85 24 DLT3u 600 110 28 DLT4u 900 135 30 DLT5u 1400 165 30 DLT6u 1900 185 30 DLT7u 2500 215 35 DLT1m 190 58 21 Applications: Lathe Machines, Machining Centers, CNC Machines, Milling Machines, Precision Grinding Machines, Drilling Machine, Turning Centers, Transfer Lines etc. DLT2m 450 85 24 DLT3m 800 110 28 DLT4m 1150 135 30 DLT5m 1750 165 30 DLT6m 2400 185 30 DLT7m 3200 215 35 DLT1p 75 58 26 Applications: Measuring & Testing Machines, Surface Plates, Hardness Testers, Microscopes, EDM Machine, Profile Projectors etc. DLT2p 175 85 29 DLT3p 300 110 33 DLT4p 500 135 35 DLT5p 700 165 35 DLT6p 950 185 35 DLT7p 1250 215 40 DLT1s2 125 58 31 Applications: Medium Presses, Punching Presses, Centreless Grinding Machines, Gear Shapers, High Speed Machines on upper floors. DLT2s2 300 85 34 DLT3s2 550 110 38 DLT4s2 850 135 40 DLT5s2 1250 165 40 DLT6s2 1700 185 40 DLT7s2 2200 215 45 DLT1s1 80 58 26 Applications: Power Presses, Stamping Machines, Shearing Machines, Punching Machines, For Machine with high vertical impact. DLT2s1 200 85 29 DLT3s1 375 110 33 DLT4s1 575 135 35 DLT5s1 800 165 35 DLT6s1 1100 185 35 DLT7s1 1500 215 40 Antivibration mounting product catalog PDFDownload Product PDF Applications of Screw Support AntiVibration Mounts Mechanical Power Presses EDM Machine Vibration Control Compressors Dynemech Anti Vibration Circular Mounts for Power Presses Dynemech Anti Vibration Mounts for CNC Dynemech Anti Vibration Machine Mounts for Injection Moulding Machines Other Models of Screw Support Levelling & Antivibration Mounts Screw Support Mounts SeriesDLC Screw Support Mounts SeriesDLK Screw Support Mounts SeriesDL Screw Support Mounts SeriesDLM Screw Support Mounts SeriesDML Vibration Isolation Pads Series DLC Isolation of vibration and noise through DLK Series Mounts Vibration Isolation AntiVibration Mounts Series DL Vibration absorbing Anti Vibration Mounts Series DLM Dynemech Mac Level Machinery Mounts Series DML Antivibration mountings manufacturer Wedge vibration control products generator mountings Wedge AVMs Pneumatic vibration isolation marine antivibration mountings Anti Vibration Pads anti vibration machinery supports Machinery Raisers AntiVibration Mountings machinery vibration stoppers, machinery installation supports stud mountings, rubber buffers anti vibration pads Bolt on height raisers TOTAL PRODUCTIVITY Mounts 3piece wedge mount for vibration damping round leveling mounts machinery anti vibration fixators round machine levellers spherical washers for tilt adjustment machinery mounts viscous spring dampers Height anti vibration pads sandwich rubber mountings Vibration Isolated Laboratory Tables autolevelingvibrationisolators Machinery Bases industrial vibration dampers machinery leveling mountingsWedge vibration control products generator mountings Wedge AVMs Pneumatic vibration isolation marine antivibration mountings Anti Vibration Pads anti vibration machinery supports Machinery Raisers AntiVibration Mountings machinery vibration stoppers, machinery installation supports stud mountings, rubber buffers anti vibration pads Bolt on height raisers TOTAL PRODUCTIVITY Mounts 3piece wedge mount for vibration damping round leveling mounts machinery anti vibration fixators round machine levellers spherical washers for tilt adjustment machinery mounts viscous spring dampers Height anti vibration pads sandwich rubber mountings Vibration Isolated Laboratory Tables autolevelingvibrationisolators Machinery Bases industrial vibration dampers machinery leveling mountings Color : Black Usage : ALL INDUSTRIAL SETUPS Product Type : VIBRATION CONTROL Function : REDUCING VIBRATION Feature : REDUCING VIBRATION

Send Inquiry

Series DLK-2 Screw Support Mounts Minimum Order Quantity : 5 Price : 830 INR/Unit Weight : Load Capacity : 1200 to 2600 kg/pc Kilograms (kg) Size : Size: Dia :135 mm & Height: 50 mm Application : Applications: Textile Machines, CNC Machines, Power Presses, Plastic injection Moulding Machines, Pressure Die Casting Machines, Printing and Textile Machines etc. Textile Machines, Compressors, Grinding Machines, All types of Heavy Industrial Applications. Color : Yellow & Red Usage : ALL INDUSTRIAL SETUPS Product Type : VIBRATION CONTROL Material : Rubber, Iron, Steel Height : Height: 50 mm Millimeter (mm)
