Product Description
Our Anti Vibration Tables - Series DIT-ALÂ are ideal for Testing / Quality Laboratories where there is need for Vibration Control from Low Frequency Vibration as well as requirement of Active Levelling system for maintaining Surface Plate Level. The Vibrations are isolated using Pneumatic Air Mounts fitted with sophisticated height sensing levelling valves. These Anti-Vibration Tables have a Granite Surface Plate with Grade-1 accuracy for very precise measuring accuracies. The system detects movement of load (like moving arm of CMM machine) on the surface plate and automatically fills/exhausts air to keep the surface plate levelled. The passive vibrations from nearby motors and other heavy machinery is reduced by 90-95%.
APPLICATIONS:Â The Vibration Isolated Table (VIT) finds usage in critical areas where reading accuracy of instruments like CMMs, Robotic Arms, Balances, Galvanometers, Electronic Microscopes and Atomic Absorption Spectrophotometers
With this specialized design, we obtain a very Precisely levelled and highly Shock Resistant Anti-Vibration Table.
Model |
Length (L) (mm) |
Width (B) (mm) |
Height (H) (mm) |
Surface Plate Thickness (mm) |
Table Loading Capacity (Kg) |
Adjustment range (mm) |
DIT-AL/01 |
500 |
500 |
800 |
50 |
100 - 250 |
8 |
DIT-AL/02 |
750 |
500 |
800 / 1000 |
80 |
200 - 450 |
8 |
DIT-AL/03 |
900 |
600 |
1000 |
100 |
500 - 1250 |
12 |
DIT-AL/04 |
1000 |
800 |
1000 |
100 |
800 - 1600 |
12 |
|
|
Anti Vibration Table
Anti Vibration Tables or Isolated Work Benches are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to high impact producing machines like power presses, hammers, crushers, generators etc. The Anti Vibration Table is designed for installing analytical and laboratory balances, high precision microscopes, Sensitive Roundness Testers and other critical and sensitive measuring and testing instruments.
Manufactured by: DYNEMECH
Model: DIT-AL/01-04
Product ID: DITAL02
