Anti Vibration Tables Series

Precision Vibration Isolation Tables P-90-01-A

Granite base of size L 750 X B 600 X T 30 mm 60 mm Tubular Structure with cross member Wrap Around Construction with left angular profile Swiveling bracket for monitor 65 X 65 mm AV pads at 8 places 4 No™s DLP3 (AV disc with adjustable screws) at Ground Level 4 No™s “ 3 Wheel Front keyboard panel for keyboard and mouse

Sleekly Dynemech Anti Vibration Precision Metrology Equipmet Table For Rondcom nex P-63

Granite base of size: L-900 B-600 T-50 mm 60x60 mm HR tubular structure with cross member 4 nos DLP3 at ground level, 4 nos - 3 wheel 9 nos AV pad between structure and granite base Front keyboard panel provided for placing keyboard & mouse over the surface Monitor Bracket on L.H Rear with swivelling and tilting fecility Structure- RAL 9002, Side sheet, door & Key board panel- Graphite Grey

Economical Anti Vibration Precision Metrology Table for Contourecord C1600-12/-13, P-65

Granite base of size: L-750 B-600 T-30 mm 60x60 mm HR tubular structure 4 nos DLP3 at ground level, 4 nos - 3 wheel 8 nos AV pad between structure and granite base Front keyboard panel provided for placing keyboard & mouse over the surface Monitor Bracket on L.H Rear with swivelling and tilting fecility Structure- RAL 9002, Side sheet, door & Key board panel- Graphite Grey Brief Description

Dynemech AVT Anti Vibration Table for Duramax CMM, P-69

Granite base of size: L-800 B-950 T-100 mm 60x60 mm HR tubular structure 4 nos DLP3 at ground level, 6 nos - 4 wheel 13 nos AV pad between structure and granite base Including 79-50 swing arm articulating assembly for keeping the Keyboard, mouse and Monitor Structure- RAL 9002, Side sheet, door & Key board panel- Graphite Grey

Laboratory Anti Vibration Table for Mahr XC2,P-71

Table surface area : L-760 B-610 H- 767 mm Granite base of size: L-750 B-600 T-30 mm 60x60 mm HR tubular structure 4 nos DLP3 at ground level, 4 nos - 3 wheel 8 nos AV pad between structure and granite base Cable manager in rear side, power strip in rear & drawing pouch L.H side Front double door Wrap around construction Front keyboard panel provided for placing keyboard & mouse over the surface Monitor Bracket can be fixed either rear L.H, front L.H and front R.H side of structure

Precision Measuring Metrology Instrument Anti Vibration Tables for SV 2100 M4/S4/H4, P-81-01-A

Granite base of size: L-750 B-600 T-30 mm 60x60 mm HR tubular structure with cross member 4 nos DLP3 at ground level, 4 nos - 3 wheel 8 nos AV pad between structure and granite base Front double door keyboard & mouse over the surface with laser cut joystick pocket with top rim and Front pivot jointed swivelling unit with data processor

Precision Measuring Metrology Instrument Anti Vibration Tables for SV 2100 W4, P-81-02-A

Granite base of size: L-1100 B-600 T-50 mm 60x60 mm HR tubular structure with cross member 4 nos DLP3 at ground level, 4 nos - 3 wheel 12 nos AV pad between structure and granite base Front double door keyboard & mouse over the surface with laser cut joystick pocket with top rim and Front pivot jointed swivelling unit with data processor

Precision Measuring Metrology Instrument Anti Vibration Tables for SV 3200 H4, P-81-03-A

Granite base of size: L-900 B-600 T-50 mm 60x60 mm HR tubular structure with cross member Front keyboard panel for keyboard and mouse, lasercut joystick pocket with top rim and Z-plates at bottom to lock joystick.

Mild Steel Anti Vibrating Table And Platforms for Surftest SV3200 H4, P-81-03-B

Granite base of size L 750 X B 600 X T 30 mm 60 mm Tubular Structure Front keyboard panel with laser cut joystick pocket for Joystick Additional printer stand to accommodate CPU console, monitor, keyboard and mouse. Pull out tray for printer. Printer stand Size 600X600mm

Quality Control Lab Table - Vibration Isolated Table for SV3200 W4, P-81-04-A

Granite base of size L 1100 X B 600 X T 50 mm 60 mm Tubular Structure with cross member Wrap Around Construction with left angular profile Swiveling bracket for monitor Front keyboard panel for keyboard and mouse, lasercut joystick pocket for Joystick

ANTI VIBRATION PRECISION METROLOGY TABLE FOR SURFCOM 480A-14 P 64

Granite base of size L 1100 X B 550 X T 50 mm 60 mm Tubular Structure with cross member to Wrap Around Construction Front pivot jointed heavy duty links with extended horizontal connecting profile and vertical 45 X 45 connecting profile. At top end another horizontal 90 X 45 profile connection with needle thrust bearing supported swiveling assembly with tray to suit display unit with clamping lever at bottom (newly introduced!). 65 X 65 mm AV pads at 9 places 4 No™s DLP3 (AV disc with adjustable screws) at Ground Level 4 No™s “ 3 Wheel Drawing Pouch L.H Side and front double door with handles and lock Leveling Ball, Spanner 24/27 Powder Coat, structure RAL 9002, side sheets and doors “ graphite gray Instrument sticker Overall dimensions: L 1120 X B 570 X H 730 (over granite base) mm Weight: kg Execution in wooden box

Quality Control Lab Table - Vibration Isolated Table for surftest , P-81-04-B

Granite base of size L 1100 X B 600 X T 30 mm 60 mm Tubular Structure 65 X 65 mm AV pads at 8 places 4 No™s DLP3 (AV disc with adjustable screws) at Ground Level 4 No™s “ 3 Wheel Front keyboard panel with laser cut joystick pocket for Joystick Additional printer stand to accommodate CPU console, monitor, keyboard and mouse. Pull out tray for printer. Printer stand Size 600X600mm

Mild Steel Laboratory Anti Vibration Table for Surftest SJ411 , P-81-05-A

Granite base of size L 600 X B 500 X T 30 mm 60 mm Tubular Structure Wrap Around Construction 65 X 65 mm AV pads at 8 places 4 No™s DLP3 (AV disc with adjustable screws) at Ground Level 4 No™s “ 3 Wheel Front keyboard for placing keyboard and mouse

Anti Vibration Table for Contracer CV3200 H4, P-82-03-A

Granite base of size: L-900 B-600 T-30 mm 60x60 mm HR tubular structure 4 nos DLP3 at ground level, 4 nos - 3 wheel 9 nos AV pad between structure and granite base Front keyboard panel provided for placing keyboard & mouse over the surface Monitor Bracket on L.H Rear with swivelling and tilting fecility

Mild Steel Anti Vibrating Table for SV 3200 W4,P-82-04-A

Granite base of size L 1100 X B 600 X T 30 mm 60 mm Tubular Structure with cross member Wrap Around Construction with left angular profile Swiveling bracket for monitor Front keyboard panel for keyboard and mouse, lasercut joystick pocket for Joystick

Precision Measuring Metrology Instrument Anti Vibration Tables for SV 3200 W4, P-82-04-B

Granite base of size L 1100 X B 600 X T 30 mm 60 mm Tubular Structure 65 X 65 mm AV pads at 8 places Front keyboard panel with laser cut joystick pocket for Joystick Additional printer stand to accommodate CPU console, monitor, keyboard and mouse. Pull out tray for printer. Printer stand Size 600X600mm

Mild Steel Anti Vibration Table AVT, For Laboratory, P-83-01-B

Granite base of size L 1000 X B 600 X T 50 mm 60 mm Tubular Structure 65 X 65 mm AV pads at 8 places Front keyboard panel with laser cut joystick pocket for Joystick Additional printer stand to accommodate CPU console, monitor, keyboard and mouse. Pull out tray for printer. Printer stand Size 600X600mm

Granite Anti Vibrating Table for Roundtest , P-84-01-B

Granite base of size L 750 X B 600 X T 30 mm 60 mm Tubular Structure 65 X 65 mm AV pads at 8 places 4 No™s DLP3 (AV disc with adjustable screws) at Ground Level 4 No™s “ 3 Wheel Front keyboard panel with laser cut joystick pocket for Joystick Additional printer stand to accommodate CPU console, monitor, keyboard and mouse. Pull out tray for printer. Printer stand Size 600X600mm

Granite Anti Vibrating Table for Roundtest with Air Cushion , P-84-02-D

Granite base of size L 750 X B 600 X T 30 mm 60 mm Tubular Structure with cross member Wrap Around Construction with left angular profile Front keyboard panel for aesthetic purpose Pneumatic supported membrane air springs with 3 sensors and auto leveling within ± 0.15 mm complete with manifold and regulator, FRL unit, shut-off wall and NRV. Completely enclosed in laser cut SS side sheet.Printer Stand (To be Ordered Separately)

Granite Anti Vibrating Table for Profile Projector , P-86-01-A

Granite size L 600 x B 900 x T 50 mm over steel structure 60 x 60 mm Square Tubular Structure with cross member Wrap around construction 4 Nos. 4™™ wheels 4 Nos. DLP4 AV discs at floor level 9 Nos. 65 x 65 mm AV Pads between Granite and structure Front double door with handles and lock

Precision Vibration Isolation Metrology Tables, P-90-01-B

Granite base of size L 1100 X B 600 X T 50 mm 60 mm Tubular Structure with cross member Wrap Around Construction with left angular profile Swiveling bracket for monitor 65 X 65 mm AV pads at 8 places 4 No™s DLP3 (AV disc with adjustable screws) at Ground Level 4 No™s “ 3 Wheel Front keyboard panel for keyboard and mouse

Dynemech Laboratory Anti Vibration Granite Table -Avant Series,P-91-01-A

Granite base of size L 1100 X B 600 X T 60 mm with keyboard panel open space for controller, drawer and space for printer

Dynemech Passive Air Cushion AVT Precision Measuring Metrology Instrument Anti Vibration Tables , P-92

Passive Air Cushion AVT with electronic alarm Granite base of size 900x600x50mm thickness Aurdino- Uno controller based with limit switches for upper and lower position with alarm buzzer and LED indicator for high/low (HAL, Bangalore)

Anti Vibration Table for Checker, P-89

Granite base of size: L 550 X B 750 X T 30 mm 60 mm Tubular Structure Wrap Around Construction Front keyboard panel to place keyboard and mouse Left rear monitor mount with bracket to hold monitor 4 No™s DLP3 (AV disc with adjustable screws) at Ground Level 4 No™s “ 3 Wheel

Anti-Vibration Table Elastomeric Material Mounts, Series DIT-E

Our customers can avail from us an excellent range of Shock Resistant Table. Designed with great care, the offered table is manufactured using best grade material and with the aid of advance technology. This table is broadly applicable in several industries; our offered table undergoes numerous tests to make certain its flawlessness. Also, our customers can take this table with different specifications & affordable rates. Features: Smooth finish Sturdiness Easy installation

Anti-Vibration Table With Auto-Levelling Pneumatic Mounts, Series DIT-AL

Our Anti Vibration Tables - Series DIT-AL are ideal for Testing / Quality Laboratories where there is need for Vibration Control from Low Frequency Vibration as well as requirement of Active Levelling system for maintaining Surface Plate Level. The Vibrations are isolated using Pneumatic Air Mounts fitted with sophisticated height sensing levelling valves. These Anti-Vibration Tables have a Granite Surface Plate with Grade-1 accuracy for very precise measuring accuracies.

Anti-Vibration Table Pneumatic Air Springs Series DIT-AS

Our Anti Vibration Tables - Series DIT-AS are ideal for isolation of LOW-FREQUENCY vibration due to working machines like presses, hammers, VMCs etc.

Scientific Lab Anti Vibration Table for Zeiss Surfcom Crest P-62

Granite base of size: L-1100 B-550 T-50 mm 60x60 mm HR tubular structure with cross member 4 nos DLP3 at ground level, 4 nos - 3 wheel 9 nos AV pad between structure and granite base Front keyboard panel provided for placing keyboard & mouse over the surface with laser cut joystick pocket with top rim and Monitor Bracket on L.H Rear with swivelling and tilting fecility Structure- RAL 9002, Side sheet, door & Key board panel- Graphite Grey

Shock Resistant / Anti-Vibration Table with Pneumatic Vibration Mounts

Dynemech Optical Honeycomb Anti Vibration Tables,Series-DIT-AM-HC

ANTI-VIBRATION TABLE WITH HONEYCOMB TABLETOP & AUTO LEVELLING PNEUMATIC VIBRATION MOUNTS
