Shock Resistant / Anti-Vibration Table with Pneumatic Vibration Mounts
Our Anti Vibration Tables - Series DIT-AS are ideal for isolation of LOW-FREQUENCY vibration due to working machines like presses, hammers, VMCs etc. The passive vibrations are absorbed by the pneumatic mounts making the surface plate float on AIR. These Anti-Vibration Tables have a Granite Surface Plate with Grade-1 accuracy for very precise measuring accuracies. These Vibration Tables provide economical solution where low frequency vibrations need to be removed. The passive vibrations from nearby motors and other heavy machinery is reduced by 90-95%.
APPLICATIONS: The Vibration Isolated Table (VIT) finds usage in critical areas where reading accuracy of instruments like CMM, Spectroscopes, Balances, Galvanometers, Electronic Microscopes and Atomic Absorption Spectrophotometers, is affected by Vibrations.
With this specialized design, we obtain a very precise and highly Shock Resistant Anti-Vibration Table.
|Model||Length (L) (mm)||Width (B) (mm)||Height (H) (mm)||Surface Plate Thickness (mm)||Table Loading Capacity (Kg)||Adjustment range (mm)|
|DIT-AS/01||500||500||800||50||100 - 250||8|
|DIT-AS/02||750||500||800 / 1000||80||200 - 450||8|
|DIT-AS/03||900||600||1000||100||500 - 1250||12|
|DIT-AS/04||1000||800||1000||100||800 - 1600||12|
