Combination Spring And Vibration Damper Isolators Series-MDI

Combination Spring And Vibration Damper Isolators Series-MDI

5280.0 INR/Piece

Get a Price/Quote

Product Details:

Spring Type Horizontal
Material Rubber, Iron, Steel, Natural Rubber, synthetic rubbers
Height 80mm To 105mm Millimeter (mm)
Function REDUCING VIBRATION
Product Type VIBRATION CONTROL
Usage ALL INDUSTRIAL SETUPS
Weight Load Capicity 110 to 5500 (kg,/pc) Kilograms (kg)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Combination Spring And Vibration Damper Isolators Series-MDI Price And Quantity

Minimum Order Quantity 4 Piece
Price 5280.0 INR/Piece

Combination Spring And Vibration Damper Isolators Series-MDI Product Specifications

Product Type VIBRATION CONTROL
Application Applications: red_arrow_bullet Power Presses red_arrow_bullet Forging Hammers red_arrow_bullet Fans red_arrow_bullet Blowers red_arrow_bullet Generating Sets red_arrow_bullet Centrifuges red_arrow_bullet Test Beds red_arrow_bullet Textile Machines red_arrow_bullet Reducing Mills and Mixers red_arrow_bullet Coal and Stone Crushers red_arrow_bullet Refrigeration Units red_arrow_bullet Pumps and Boilers etc. red_arrow_bullet All types of heavy industrial machinery
Height 80mm To 105mm Millimeter (mm)
Usage ALL INDUSTRIAL SETUPS
Function REDUCING VIBRATION
Material Rubber, Iron, Steel, Natural Rubber, synthetic rubbers
Color BLUE
Spring Type Horizontal
Size Size: Dia - HO:69mm To 96mm & Ht - 80mm To 105mm
Weight Load Capicity 110 to 5500 (kg,/pc) Kilograms (kg)
Feature REDUCING VIBRATION

Combination Spring And Vibration Damper Isolators Series-MDI Trade Information

FOB Port RAI
Supply Ability 100 Piece Per Day
Delivery Time 2 Days
Sample Policy Contact us for information regarding our sample policy
Packaging Details PROPER STANDARD PACKING (OR AS PER PARTY REQUIREMENT )
Main Export Market(s) Australia, North America, Eastern Europe, Western Europe, Central America, Middle East, South America, Asia, Africa
Main Domestic Market Himachal Pradesh, Andaman and Nicobar Islands, Uttarakhand, Daman and Diu, Dadra and Nagar Haveli, Lakshadweep, South India, North India, East India, Andhra Pradesh, Assam, Arunachal Pradesh, Bihar, Chandigarh, Delhi, Gujarat, Goa, Haryana, Jammu and Kashmir, Jharkhand, Karnataka, Madhya Pradesh, Maharashtra, Mizoram, Meghalaya, Manipur, Punjab, Pondicherry, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, West Bengal, Nagaland, Kerala, Central India, Odisha, West India, Chhattisgarh, Uttar Pradesh, All India
Certifications ISO 9001:2015

Product Description

A spring isolator gives desired natural frequency to obtain phase difference in the frequencies for a rotating machine and impact generating machine. Viscous damping is an important feature of an isolation system. In most cases viscous damping is required to limit excessive movement which could occur as a machine operates at a speed near to, or coinciding with the resonant frequencies of the system. Generally this problem arises during slow run up and run down of rotating machines and during impact at each stroke in presses and hammers.
