Dynemech Membrane Air Spring , Series DMAS-SL

1 INR/Number

Get a Price/Quote

Product Details:

Color Grey
Product Type Anti Vibration Mount
Size 110X102X190 TO 250X110X330
Length 190 TO 330 Millimeter (mm)
Usage For control vibration related problems
Height 102 TO 110 Millimeter (mm)
Function Control Vibration -smooth function
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Dynemech Membrane Air Spring , Series DMAS-SL Price And Quantity

Minimum Order Quantity 2 Number
Price 1 INR/Number

Dynemech Membrane Air Spring , Series DMAS-SL Product Specifications

Product Type Anti Vibration Mount
Color Grey
Size 110X102X190 TO 250X110X330
Function Control Vibration -smooth function
Length 190 TO 330 Millimeter (mm)
Height 102 TO 110 Millimeter (mm)
Usage For control vibration related problems

Dynemech Membrane Air Spring , Series DMAS-SL Trade Information

FOB Port Haryana
Payment Terms Cash Against Delivery (CAD) Cash on Delivery (COD) Cash Advance (CA) Cash in Advance (CID) Cheque
Supply Ability 2 Number Per Day
Delivery Time 2 Days
Sample Policy Contact us for information regarding our sample policy
Packaging Details ISO, TRADEMARK, MSME,

Product Description

Dynemech DMAS system consists of three master pneumatic isolators for 3-point precision levelling. Each pneumatic damping isolator consists of a self-levelling plunger mechanism, which is the load sensing, and height-controlling element. The system is supplied with pressure regulator, distributor, non-return valve and other pneumatic accessories necessary for complete systems installation. Clean dry air is required to be supplied to the system.

The DMAS is lightweight aluminium body. The inner chamber is split into two parts i.e. load volume and damping volume. Damping up to 20% can be adjusted using external valve manually. A thin reinforced elastomeric diaphragm supports the load. A safety valve protects diaphragm from over inflation. The final precise levelling of the system can be done using levelling nut provided on the plunger mechanism.

Available levelling accuracies are ± 0.015 mm and ± 0.15 mm depending upon the application requirements.

Natural Frequency of the DMAS system is 2.5-3 Hz.
