Machine Base Mounts , Series SLM (M)

Machine Base Mounts , Series SLM (M)

1 INR/Number,

Product Details:

  • Weight Load Capacity : 220 to 11500 kg/pc Kilograms (kg)
  • Width 64mm To 200mm Millimeter (mm)
  • Product Type VIBRATION CONTROL
  • Color GREY
  • Size 75mmX64mmX29mm & 200mmX200mmX49mm
  • Length 75mm TO 200mm Millimeter (mm)
  • Usage ALL INDUSTRIAL SETUPS
  • Click to View more
X

Machine Base Mounts , Series SLM (M) Price And Quantity

  • 5 Number,
  • 1 INR/Number,

Machine Base Mounts , Series SLM (M) Product Specifications

  • ALL INDUSTRIAL SETUPS
  • 75mm TO 200mm Millimeter (mm)
  • REDUCING VIBRATION
  • 29mm TO 49MM Millimeter (mm)
  • 64mm To 200mm Millimeter (mm)
  • GREY
  • 75mmX64mmX29mm & 200mmX200mmX49mm
  • Applications: Industrial production and processing centres, assembly stations and in equipments such as Compressors, Tool Room Machines, Plastic injection Moulding Machines,, Printing and Textile Machines, Centreless Grinding Machines, Gear Shapers, High Speed Machines on uppe
  • VIBRATION CONTROL
  • Rubber, Iron, Steel
  • Load Capacity : 220 to 11500 kg/pc Kilograms (kg)

Machine Base Mounts , Series SLM (M) Trade Information

  • RAI
  • Cash on Delivery (COD), Cash Against Delivery (CAD), Cash in Advance (CID), Cheque, Cash Advance (CA),
  • 200 Number, Per Day
  • 6-7 Days
  • Contact us for information regarding our sample policy,
  • Wooden Box & Corrugated Box as per your requirement
  • Australia, North America, South America, Eastern Europe, Western Europe, Middle East, Africa, Central America, Asia,
  • Manipur, Himachal Pradesh, Andaman and Nicobar Islands, Pondicherry, Uttarakhand, Daman and Diu, Dadra and Nagar Haveli, Lakshadweep, , South India, North India, East India, Andhra Pradesh, Assam, Arunachal Pradesh, Bihar, Chandigarh, Goa, Haryana, Jammu and Kashmir, Jharkhand, Karnataka, Kerala, Madhya Pradesh, Maharashtra, Mizoram, Meghalaya, Punjab, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, West Bengal, Nagaland, Delhi, Gujarat, Central India, Odisha, West India, Chhattisgarh, Uttar Pradesh, All India,
  • ISO 9001:2015

Product Description

Dynemech Machine Base Mounts - Series SLM


Dynemech Machine Base Mounts, SLM Series Anti Vibration Mounts having square/rectangular base, developed in cast iron body allow anchor-free machinery installations.


These are available in three variants of M, RA and F.


Type M - The bolt can rotate on its axis and moves radially provides compensation of ground unevenness of up to 5° and simple levelling with a great levelling range. The levelling is done by rotating the hex provided at the base of the bolt just above the mount body. Machine base must have a tapped hole. One free nut and washer  is provided for clamping after the levelling is completed.


Type RA - The bolt can rotate on its axis and provides simple levelling with a great levelling range. The levelling is done by rotating the hex provided at the base of the bolt just above the mount body. Machine base must have a tapped hole. One free nut and washer  is provided for clamping after the levelling is completed.


Type F - The bolt is fixed with the mount body. Two free nuts and a washer is provided. Machine base rests over the bottom nut and washer. Levelling is done by rotating the bottom nut. Machine base must have plain holes. The top nut is used for clamping after the levelling is completed.



SLM Series are easy-to-install  , maintenance free and effective vibration dampers for machines with respective plain/tapped holes in the base.

These mounts offer low frequency attenuation, stable machine levelling and vibration reduction.


High friction grip and vibration reduction at the bottom is achieved through elastomeric vibration insulation sheets  so machines don’t move.




Applications: Industrial production and processing centres, assembly stations and in equipments such as  Compressors, Tool Room Machines, Plastic injection Moulding Machines,, Printing and Textile Machines, Centreless Grinding Machines, Gear Shapers, High Speed Machines on upper floors, etc.
