Machine Base Mounts , Series SLM (RA)
Machine Base Mounts , Series SLM (RA)

Machine Base Mounts , Series SLM (RA)

Price 1 INR/ Number

Machine Base Mounts , Series SLM (RA) Specification

  • Material
  • Rubber, Iron, Steel
  • Function
  • REDUCING VIBRATION
  • Height
  • 29mm TO 49MM Millimeter (mm)
  • Product Type
  • VIBRATION CONTROL
  • Usage
  • ALL INDUSTRIAL SETUPS
  • Weight
  • Load Capacity : 220 to 11500 kg/pc Kilograms (kg)
  • Size
  • 75mmX64mmX29mm & 200mmX200mmX49mm
  • Length
  • 75mm TO 200mm Millimeter (mm)
  • Color
  • GREY
  • Width
  • 64mm To 200mm Millimeter (mm)
  • Application
  • Applications: Industrial production and processing centres, assembly stations and in equipments such as Compressors, Tool Room Machines, Plastic injection Moulding Machines,, Printing and Textile Machines, Centreless Grinding Machines, Gear Shapers, High Speed Machines on uppe


Machine Base Mounts , Series SLM (RA) Trade Information

  • Minimum Order Quantity
  • 5 Number
  • FOB Port
  • RAI
  • Payment Terms
  • Cash on Delivery (COD), Cash Advance (CA), Cheque, Cash Against Delivery (CAD), Cash in Advance (CID)
  • Supply Ability
  • 200 Per Day
  • Delivery Time
  • 6-7 Days
  • Sample Policy
  • Contact us for information regarding our sample policy
  • Packaging Details
  • Wooden Box & Corrugated Box as per your requirement
  • Main Export Market(s)
  • Western Europe, Middle East, Central America, South America, Asia, Eastern Europe, North America, Australia, Africa
  • Main Domestic Market
  • Assam, Dadra and Nagar Haveli, Chandigarh, Manipur, Andaman and Nicobar Islands, Pondicherry, Uttarakhand, Lakshadweep, , South India, North India, East India, West India, Arunachal Pradesh, Bihar, Chhattisgarh, Daman and Diu, Goa, Haryana, Himachal Pradesh, Jammu and Kashmir, Kerala, Madhya Pradesh, Maharashtra, Mizoram, Meghalaya, Nagaland, Punjab, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, West Bengal, Odisha, Delhi, Gujarat, Karnataka, Andhra Pradesh, Central India, Jharkhand, Uttar Pradesh, All India
  • Certifications
  • ISO 9001:2015


Machine Base Mounts , Series SLM (RA) About

Dynemech Machine Base Mounts - Series SLM


Dynemech Machine Base Mounts, SLM Series Anti Vibration Mounts having square/rectangular base, developed in cast iron body allow anchor-free machinery installations.


These are available in three variants of M, RA and F.


Type M - The bolt can rotate on its axis and moves radially provides compensation of ground unevenness of up to 5° and simple levelling with a great levelling range. The levelling is done by rotating the hex provided at the base of the bolt just above the mount body. Machine base must have a tapped hole. One free nut and washer  is provided for clamping after the levelling is completed.


Type RA - The bolt can rotate on its axis and provides simple levelling with a great levelling range. The levelling is done by rotating the hex provided at the base of the bolt just above the mount body. Machine base must have a tapped hole. One free nut and washer  is provided for clamping after the levelling is completed.


Type F - The bolt is fixed with the mount body. Two free nuts and a washer is provided. Machine base rests over the bottom nut and washer. Levelling is done by rotating the bottom nut. Machine base must have plain holes. The top nut is used for clamping after the levelling is completed.



SLM Series are easy-to-install  , maintenance free and effective vibration dampers for machines with respective plain/tapped holes in the base.

These mounts offer low frequency attenuation, stable machine levelling and vibration reduction.


High friction grip and vibration reduction at the bottom is achieved through elastomeric vibration insulation sheets  so machines don’t move.




Applications: Industrial production and processing centres, assembly stations and in equipments such as  Compressors, Tool Room Machines, Plastic injection Moulding Machines,, Printing and Textile Machines, Centreless Grinding Machines, Gear Shapers, High Speed Machines on upper floors, etc.
