WEDGE MOUNTS, SERIES DT (BOLT THU)

1475 INR/Number

Get a Price/Quote

Product Details:

Color Green
Size 100x100x53mm To x400x500X105mm
Product Type VIBRATION CONTROL
Length 100mm To 400mm Millimeter (mm)
Weight Load Capicity 900 to 26000 (kg,/pc) Kilograms (kg)
Usage ALL INDUSTRIAL SETUPS
Material Rubber Iron synthetic rubbers
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

WEDGE MOUNTS, SERIES DT (BOLT THU) Price And Quantity

Minimum Order Quantity 50 Number
Price 1475 INR/Number

WEDGE MOUNTS, SERIES DT (BOLT THU) Product Specifications

Usage ALL INDUSTRIAL SETUPS
Weight Load Capicity 900 to 26000 (kg,/pc) Kilograms (kg)
Function REDUCING VIBRATION
Length 100mm To 400mm Millimeter (mm)
Product Type VIBRATION CONTROL
Application Drilling and milling machines, machining centres, special machines, long lathes, long planers, power presses etc.
Size 100x100x53mm To x400x500X105mm
Material Rubber Iron synthetic rubbers
Feature REDUCING VIBRATION
Color Green

WEDGE MOUNTS, SERIES DT (BOLT THU) Trade Information

FOB Port RAI
Payment Terms Cash on Delivery (COD) Cash Against Delivery (CAD) Cash in Advance (CID) Cheque Cash Advance (CA)
Supply Ability 300 Number Per Day
Delivery Time 8-9 Days
Packaging Details Wooden Box & Corrugated Box as per your requirement
Main Export Market(s) Western Europe Australia North America Eastern Europe Middle East Central America South America Asia Africa
Main Domestic Market Manipur Himachal Pradesh Andaman and Nicobar Islands Nagaland Uttarakhand Daman and Diu Dadra and Nagar Haveli Lakshadweep South India East India West India Assam Arunachal Pradesh Bihar Chandigarh Delhi Gujarat Goa Haryana Jammu and Kashmir Jharkhand Karnataka Madhya Pradesh Maharashtra Mizoram Meghalaya Punjab Pondicherry Rajasthan Sikkim Tamil Nadu Telangana Tripura Uttar Pradesh West Bengal North India Andhra Pradesh Kerala Central India Odisha Chhattisgarh All India
Certifications ISO 9001:2015

Product Description

Wedge Mounts - Series DT (Bolt Through)

Dynemech Wedge Mounts, Series DT are designed for machines which are top heavy or have eccentric motion or machines which must be anchored to the ground.

Range of Applications:

Drilling and milling machines, machining centres, special machines, long lathes, long planers, power presses etc.

Model	Load (Kg/pc)	Length (L) (mm)	Width (B) (mm)	Height (H) at mean position (mm)	d (mm)	e (mm)	Bore Ã˜ size (mm)	Adjustment range (mm)
DT1-u	1100	115	115	59	50	24	22	8
DT2-u	1800	150	150	64	60	23	22	10
DT3-u	3200	200	200	63	75	27	28	12
DT4-u	4000	200	250	85	95	27	28	18
DT5-u	6400	250	320	90	125	55	28	18
DT6-u	9600	300	400	90	148	50	30	20
DT1-m	1400	115	115	59	50	24	22	8
DT2-m	2200	150	150	64	60	23	22	10
DT3-m	4000	200	200	63	75	27	28	12
DT4-m	5000	200	250	85	95	27	28	18
DT5-m	8000	250	320	90	125	55	28	18
DT6-m	12000	300	400	90	148	50	30	20
DT1-i	1800	115	115	69	50	24	22	8
DT2-i	2900	150	150	74	60	23	22	10
DT3-i	5200	200	200	73	75	27	28	12
DT4-i	6500	200	250	95	95	27	28	18
DT5-i	10000	250	320	100	125	55	28	18
DT6-i	15000	300	400	100	148	50	30	20
DT1-s2	950	115	115	69	50	24	22	8
DT2-s2	1600	150	150	74	60	23	22	10
DT3-s2	2800	200	200	73	75	27	28	12
DT4-s2	3500	200	250	95	95	27	28	18
DT5-s2	5500	250	320	100	125	55	28	18
DT6-s2	8500	300	400	100	148	50	30	20

Model	Load (Kg/pc)	Length (L) (mm)	Width (B) (mm)	Height (H) at mean position (mm)	d (mm)	e (mm)	Bore Ã˜ size (mm)	Adjustment range (mm)	Remarks
DT1	3600	115	115	44	50	24	22	8	No Vibration Isolation. Only 3-piece Precision Levelling Wedge Mount.
DT2	5800	150	150	49	60	23	22	10
DT3	10400	200	200	48	75	27	28	12
DT4	13000	200	250	70	95	27	28	18
DT5	20000	250	320	75	125	55	28	18
DT6	30000	300	400	75	148	50	30	2
