Wedge Mounts, Series DTPH

1 INR/Number

Get a Price/Quote

Product Details:

Size 200x125x150mm To 280x170x200mm
Length 200mm To 280mm Millimeter (mm)
Weight Load Capacity : 2250 to 23000 kg/pc Kilograms (kg)
Product Type VIBRATION CONTROL
Color Green
Usage ALL INDUSTRIAL SETUPS
Width 125mm to 170mm Millimeter (mm)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Price And Quantity

Price 1 INR/Number
Minimum Order Quantity 50 Number

Product Specifications

Usage ALL INDUSTRIAL SETUPS
Color Green
Height 88mm to 160mm Millimeter (mm)
Application DTPH Series mounts are available in three options - Free Standing, Bolt-On and Bolt-Through
Feature REDUCING VIBRATION
Width 125mm to 170mm Millimeter (mm)
Function REDUCING VIBRATION
Product Type VIBRATION CONTROL
Material Rubber Iron Steel Polyurethane Natural Rubber
Weight Load Capacity : 2250 to 23000 kg/pc Kilograms (kg)
Length 200mm To 280mm Millimeter (mm)
Size 200x125x150mm To 280x170x200mm

Trade Information

FOB Port RAI
Payment Terms Cash Against Delivery (CAD) Cash on Delivery (COD) Cash Advance (CA) Cash in Advance (CID) Cheque
Supply Ability 300 Number Per Day
Delivery Time 6-7 Days
Packaging Details Wooden Box & Corrugated Box as per your requirement.
Main Export Market(s) Western Europe Australia North America South America Eastern Europe Middle East Central America Asia Africa
Main Domestic Market Dadra and Nagar Haveli Andaman and Nicobar Islands Nagaland Uttarakhand Daman and Diu Lakshadweep South India Assam Arunachal Pradesh Bihar Chandigarh Delhi Goa Himachal Pradesh Jammu and Kashmir Maharashtra Mizoram Meghalaya Manipur Punjab Pondicherry Rajasthan Sikkim Tamil Nadu Telangana Tripura West Bengal Kerala Gujarat Haryana Madhya Pradesh Karnataka North India East India Andhra Pradesh Central India Odisha Jharkhand West India Chhattisgarh Uttar Pradesh All India
Certifications ISO 9001:2015

Product Description

Wedge Mounts - Series DTPH

Dynemech's DTPH Series mounts are designed for machines which require very high height adjustment and precision levelling. Variations are available for free standing and bolt on machine bases either with or without insulation damping. Dynemech also provides tailor made solutions besides providing quick installation service.

WEDGE MOUNT - DTPH SERIES
Â	Â	Â	Â	Â	Â	Â	Â	Â	Â	Â	Â	Â	Â	Â
Model	Load Capacity Kg/pc	Length (L) mm	WidthÂ (B) mm	Height (H) at mean position (mm)	d (mm)	e (mm)	BORE* (mm)	Adjustment Â Range (mm)	Bottom pad Type	Bottom pad Thickness (mm)	SW1 (mm)	SW2 (mm)	Coeff. of Friction against Concrete	Natural Frequency at Max. Load (Hz)
DTPH1-u	2250	200	125	150	75	25	25	16	Du	15	22	12	0.9	18
DTPH2-u	2700	200	150	150	75	25	25	20	Du	15	22	12	0.9	18
DTPH3-u	4200	280	170	200	145	30	28	25	Du	15	39	22	0.9	18
DTPH1-m	2500	200	125	150	75	25	25	16	Dm	15	22	12	0.7	30
DTPH2-m	3000	200	150	150	75	25	25	20	Dm	15	22	12	0.7	30
DTPH3-m	4600	280	170	200	145	30	28	25	Dm	15	39	22	0.7	30
DTPH1-i	3500	200	125	150	75	25	25	16	Di	25	22	12	0.8	7
DTPH2-i	4200	200	150	150	75	25	25	20	Di	25	22	12	0.8	7
DTPH3-i	6400	280	170	200	145	30	28	25	Di	25	39	22	0.8	7
DTPH1-h	7500	200	125	150	75	25	25	16	Dh	15	22	12	0.6	45
DTPH2-h	9000	200	150	150	75	25	25	20	Dh	15	22	12	0.6	45
DTPH3-h	14000	280	170	200	145	30	28	25	Dh	15	39	22	0.6	45
DTPH1-p1	1000	200	125	150	75	25	25	16	Dp1Â	15	22	12	0.8	7
DTPH2-p1	1200	200	150	150	75	25	25	20	Dp1Â	15	22	12	0.8	7
DTPH3-p1	1900	280	170	200	145	30	28	25	Dp1Â	15	39	22	0.8	7
DTPH1-p2	1250	200	125	150	75	25	25	16	Dp2	20	22	12	0.8	12
DTPH2-p2	1500	200	150	150	75	25	25	20	Dp2	20	22	12	0.8	12
DTPH3-p2	2380	280	170	200	145	30	28	25	Dp2	20	39	22	0.8	12
DTPH1-p3	1500	200	125	150	75	25	25	16	Dp3	24	22	12	0.8	7
DTPH2-p3	1800	200	150	150	75	25	25	20	Dp3	24	22	12	0.8	7
DTPH3-p3	2860	280	170	200	145	30	28	25	Dp3	24	39	22	0.8	7
DTPH1-s1	1250	200	125	150	75	25	25	16	Ds1	20	22	12	0.8	15
DTPH2-s1	1500	200	150	150	75	25	25	20	Ds1	20	22	12	0.8	15
DTPH3-s1	2380	280	170	200	145	30	28	25	Ds1	20	39	22	0.8	15
DTPH1-s2	2000	200	125	150	75	25	25	16	Ds2	25	22	12	0.8	8
DTPH2-s2	2400	200	150	150	75	25	25	20	Ds2	25	22	12	0.8	8
DTPH3-s2	3800	280	170	200	145	30	28	25	Ds2	25	39	22	0.8	8
DTPH1-hs1	5000	200	125	150	75	25	25	16	Dhs1	65	22	12	0.8	6
DTPH2-hs1	6000	200	150	150	75	25	25	20	Dhs1	65	22	12	0.8	6
DTPH3-hs1	9520	280	170	200	145	30	28	25	Dhs1	65	39	22	0.8	6
DTPH1-hs2	2000	200	125	150	75	25	25	16	Dhs2	65	22	12	0.8	4
DTPH2-hs2	2400	200	150	150	75	25	25	20	Dhs2	65	22	12	0.8	4
DTPH3-hs2	3800	280	170	200	145	30	28	25	Dhs2	65	39	22	0.8	4
DTPH1-hs3	7000	200	125	150	75	25	25	16	Dhs3	50	22	12	0.8	7
DTPH2-hs3	8400	200	150	200	75	25	25	20	Dhs3	50	22	12	0.8	7
DTPH3-hs3	13330	280	170	200	145	30	28	25	Dhs3	50	39	22	0.8	7
DTPH1-hs4	3000	200	125	150	75	25	25	16	Dhs4	50	22	12	0.8	5
DTPH2-hs4	3600	200	150	200	75	25	25	20	Dhs4	50	22	12	0.8	5
DTPH3-hs4	5700	280	170	200	145	30	28	25	Dhs4	50	39	22	0.8	5
DTPH1-hs5	7000	200	125	200	75	25	25	16	Dhs5	80	22	12	0.8	5
DTPH2-hs5	8400	200	150	200	75	25	25	20	Dhs5	80	22	12	0.8	5
DTPH3-hs5	13330	280	170	200	145	30	28	25	Dhs5	80	39	22	0.8	5
DTPH1-a1	4500	200	125	150	75	25	25	16	Da1	2	22	12	0.8	Â
DTPH2-a1	5400	200	150	150	75	25	25	20	Da1	2	22	12	0.8	Â
DTPH3-a1	8570	280	170	200	145	30	28	25	Da1	2	39	22	0.8	Â
DTPH1-a2	2500	200	125	150	75	25	25	16	Da2	8	22	12	0.9	Â
DTPH2-a2	3000	200	150	150	75	25	25	20	Da2	8	22	12	0.9	Â
DTPH3-a2	4760	280	170	200	145	30	28	25	Da2	8	39	22	0.9	Â
DTPH1	13000	200	125	150	75	25	25	16	X	X	22	12	X	X
DTPH2	16000	200	150	150	75	25	25	20	X	X	22	12	X	X
DTPH3	23000	280	170	200	145	30	28	25	X	X	39	22	X	X
