Wedge Mounts, Series DTP (BOLT THRU)

2830 INR/Number

Get a Price/Quote

Product Details:

Product Type Vibration Control
Weight 1100 kg to 15000 kg approx Kilograms (kg)
Color GREEN
Length 115 To 300mm Millimeter (mm)
Height 100 To 150mm Millimeter (mm)
Width 115 To 400mm Millimeter (mm)
Size 115x115x150mm To 300x400x150mm
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Wedge Mounts, Series DTP (BOLT THRU) Price And Quantity

Minimum Order Quantity 5 Number
Price 2830 INR/Number

Wedge Mounts, Series DTP (BOLT THRU) Product Specifications

Function REDUCING VIBRATION
Weight 1100 kg to 15000 kg approx Kilograms (kg)
Material Rubber Iron Natural Rubber synthetic rubbers
Product Type Vibration Control
Application Drilling and milling machines, machining centres, special machines, long lathes, long planers, power presses etc.
Size 115x115x150mm To 300x400x150mm
Height 100 To 150mm Millimeter (mm)
Width 115 To 400mm Millimeter (mm)
Usage ALL INDUSTRIAL SETUPS
Color GREEN
Length 115 To 300mm Millimeter (mm)

Wedge Mounts, Series DTP (BOLT THRU) Trade Information

FOB Port RAI
Payment Terms Cash on Delivery (COD) Cheque Cash Against Delivery (CAD) Cash in Advance (CID) Cash Advance (CA)
Supply Ability 300 Number Per Day
Delivery Time 7 Days
Sample Policy Contact us for information regarding our sample policy
Packaging Details Corrugated Packing
Main Export Market(s) Asia Australia North America South America Eastern Europe Western Europe Middle East Central America Africa
Main Domestic Market Dadra and Nagar Haveli Andaman and Nicobar Islands Pondicherry Uttarakhand Daman and Diu Lakshadweep South India East India Assam Arunachal Pradesh Bihar Chandigarh Goa Haryana Jammu and Kashmir Jharkhand Karnataka Madhya Pradesh Maharashtra Mizoram Meghalaya Manipur Punjab Rajasthan Sikkim Tamil Nadu Telangana Tripura West Bengal Nagaland Delhi Gujarat North India Andhra Pradesh Kerala Central India Odisha West India Chhattisgarh Himachal Pradesh Uttar Pradesh All India
Certifications ISO 9001:2015

Product Description

Anti-Vibration mounts - TPM Series Mount Series DTP

TPM Series Mounts - Series DTP (Bolt Through)

TPM Series Mounts are designed for industrial machines that require the machines to be placed at a height of 100mm / 150mm for proper cleaning and repairing under the machine as per IMTMA guidelines. Series DTP are designed for machines which are top heavy or have eccentric motion or machines which must be anchored to the ground.

Range of Applications:

Drilling and milling machines, machining centres, special machines, long lathes, long planers, power presses etc.

Model	Load (Kg/pc)	Length (L) (mm)	Width (B) (mm)	Height (H) at mean position (mm)	d (mm)	e (mm)	Bore Ã˜ size (mm)	Adjustment range (mm)
DTP1-u	1100	115	115	100 / 150	50	24	22	8
DTP2-u	1800	150	150	100 / 150	60	23	22	10
DTP3-u	3200	200	200	100 / 150	75	27	28	12
DTP4-u	4000	200	250	100 / 150	95	27	28	18
DTP5-u	6400	250	320	100 / 150	125	55	28	18
DTP6-u	9600	300	400	100 / 150	148	50	30	20
DTP1-m	1400	115	115	100 / 150	50	24	22	8
DTP2-m	2200	150	150	100 / 150	60	23	22	10
DTP3-m	4000	200	200	100 / 150	75	27	28	12
DTP4-m	5000	200	250	100 / 150	95	27	28	18
DTP5-m	8000	250	320	100 / 150	125	55	28	18
DTP6-m	12000	300	400	100 / 150	148	50	30	20
DTP1-i	1800	115	115	100 / 150	50	24	22	8
DTP2-i	2900	150	150	100 / 150	60	23	22	10
DTP3-i	5200	200	200	100 / 150	75	27	28	12
DTP4-i	6500	200	250	100 / 150	95	27	28	18
DTP5-i	10000	250	320	100 / 150	125	55	28	18
DTP6-i	15000	300	400	100 / 150	148	50	30	20
DTP1-s2	950	115	115	100 / 150	50	24	22	8
DTP2-s2	1600	150	150	100 / 150	60	23	22	10
DTP3-s2	2800	200	200	100 / 150	75	27	28	12
DTP4-s2	3500	200	250	100 / 150	95	27	28	18
DTP5-s2	5500	250	320	100 / 150	125	55	28	18
DTP6-s2	8500	300	400	100 / 150	148	50	30	20
