Wedge Mounts - Series DF Wedge Mounts Series DF (Free Standing)

Wedge Mounts - Series DF Wedge Mounts Series DF (Free Standing)

13,850 INR/Unit

Product Details:

  • Color Green
  • Size 105x55 mm TO 400x400 mm
  • Product Type Anti-Vibration and Shock Control
  • Usage No Vibration Isolation. Only 3-piece Precision Levelling Wedge Mount.
  • Material Iron, Rubber
  • Function Freely placed on the mounts (Series DF)
  • Application Top anti skid plate Da2 & bottom Insulation plate Du. Applications: Tool Room Machines, Plastic injection Moulding Machines, Pressure Die Casting Machines, Shaper, Printing and Textile Machines etc.
  • Supply Ability : 2 Unit Per Day
  • Click to view more
X

Price And Quantity

  • 2 nos Unit
  • 13,850 INR/Unit

Product Specifications

  • Top anti skid plate Da2 & bottom Insulation plate Du. Applications: Tool Room Machines, Plastic injection Moulding Machines, Pressure Die Casting Machines, Shaper, Printing and Textile Machines etc.
  • No Vibration Isolation. Only 3-piece Precision Levelling Wedge Mount.
  • Anti-Vibration and Shock Control
  • 105x55 mm TO 400x400 mm
  • Green
  • Iron, Rubber
  • Vibration reduction is possible through assembling respective Dynemech insulation plates.
  • Freely placed on the mounts (Series DF)

Trade Information

  • Extra and actual
  • Cheque, Cash in Advance (CID), Cash Advance (CA)
  • 2 Unit Per Day
  • 2 Days
  • Yes
  • Free samples available with shipping and taxes paid by the buyer
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • Certifications:ROHS ,IEC CODE, ISO, REX REGISTRATION, CE MARKING,

Product Description

Dynemech Wedge Mounts, Series DF (Wedge Mounts- Free Standing)are designed for industrial machinery that require precision levelling, vibration absorption and stable support.

This finds application in machines such as injection-molding machines, lathes with long beds, CNC machine centres, and other machines used in engineering industry, plastics industry, machine tool industry, textiles, steel industry etc.

This three-piece wedge mount has a centrally located adjustable bolt which moves the centre wedge between the top & bottom wedges.

These three machined wedges are held together by a horizontal adjusting bolt and the retaining pin. Guiding the wedges on the key provides accurate levelling and the retaining pin secures the mount in the levelled position.

Anti - skid plate is provided on the top wedge; therefore, machines are installed as free standing. Greater supporting area ensures solidity, rigidity, and stable machine installation.

Vibration Control is possible through assembling respective Dynemech insulation plates, depending upon the type and frequency of vibration generated by the machines.

Product details

Usage/Application

Industrial

Weight

1.5 kg To 100 kg

Reduces

Shock,Vibrations

Finishing

Painted

Color

Grey,Green

Size

105x55 mm TO 400x400 mm

Material

Composite Elastomeric Material and Metal
